GEPRC SPEEDX2 2207E Motor

Summary

The SPEEDX2 2207E series features a sleek, all-black glossy design with extensive cutouts for optimal heat dissipation, ensuring durability and impact resistance. Its high responsiveness provides effortless control in every maneuver.

Feature

1. Reduced rotor-stator gap ensures rapid response for seamless freestyle flying.
2.  The fresh all-black glossy design with extensive cutouts enhances heat dissipation for better performance.
3.  Crafted from 7075 aerospace-grade aluminum with precision CNC machining for a lightweight design.

Specifications

• Model: SPEEDX2 2207E Motor
• KV: 1960
• Max Watt: 1104.7W
• Peak Current: 44.57A
• Interphase Resistance: 69.85mΩ
• Propeller: 4-5inch-3blade
• Magnet: N52H
• Bearing: NMB/NSK
• Stator Configuration: 12N14P
• Dimension: 28*19.6mm
• Shaft Diameter: 5mm
• Shaft Length: 13.5mm
• Mounting Hole Size: 16*16mm
• Wire Specification: 20AWG/150mm
• Compatible ESC: 50A/6S
• Input Voltage: 6S
• Winding: Single-strand copper winding
• Color: Black
• Weight: 34.5g (including wire)
• Compatible Models: Suitable for 4inch-5inch racing FPV quads
